  • Page 1 English User manual IVP 4000 smart...
  • Page 2 Passive infrared sensor Congratulations, you have just purchased a product with Intelbras quality and safety. The passive infrared sensor IVP 4000 smart was developed by Intelbras with 100% digital technology. The sensor has an integrated Temperature Sensor to offer the same detection sensitivity in different environments (from -10 to +50°) reducing the risk of false triggers,...
  • Page 3 Care and safety » LGPD – Data processing by Intelbras: Intelbras does not access, transfer, capture or carry out any type of processing of personal data of this product. » Follow all the instructions in the manual to assemble and install the product;...
  • Page 4 Scan 115º Upper view Detection area 1.8 ~2.20m 2.0 ~ 2.20 m Side view...

  • Page 5: Table Of Contents

    10.1. IVP 4000 smart sensor sensitivity adjustment ........

  • Page 6: Technical Specifications

    1. Technical specifications Operating voltage 3Vdc Operating current < 20 mA Detection angle 115° Detection range 12 m Operating Temperature - 10 °C to + 50 °C Transmission frequency 433,92 MHz Detection method Battery LITHIUM CR123A 3 V Supervision Supervised (FSK) or unsupervised (OOK) Anti-jamming Immunity against interference from malicious signals 2.

  • Page 7: Sensor Aperture

    4. Sensor aperture To access the IVP 4000 SMART sensor board for battery change or configuration, squeeze the base latch, located at the bottom. See image below: SENTIDO DE SOLDA IVP 4000 SMART OOK/FSK CONT SENS BATERIA 5. Sensor stabilization After inserting the battery, the sensor goes into stabilization mode and the blue LED flashes for a few seconds.

  • Page 8: Installation

    » Make sure the sensor is securely fixed and not subject to jitter in order to avoid unwanted triggers. The IVP 4000 SMART sensor does not have an articulator, as it already has a 15° inclination angle. Therefore, for its ins- tallation, follow the procedure: 1.

  • Page 9: Trial Period

    Note: if the control panel used is Intelbras, put it in test mode, this way it will not be necessary to observe the LED, as the control panel will indicate the sensor operation through siren beeps. For more information, consult the central manual on the website: www.intelbras.com.br.

  • Page 10: Ivp 4000 Smart Sensor Sensitivity Adjustment

    With jumper JP1 in position 2 the sensor provides minimum sensitivity. Factory default: position 2 (minimum). 10.2. IVP 4000 smart sensor operating mode setting Through jumper ECO/CONT (JP2), select between intelligent continuous mode and economic mode. With jumper JP2 in position 1 the sensor is in continuous intelligent mode.

  • Page 11: Ivp 4000 Smart Sensor Supervision Setting

    Factory default: unsupervised 10.4. Low battery sensor The IVP 4000 SMART sensor controls the battery level and if it is critical (equal to or below 2.5 V), it sends the information to the alarm control panel. » If the sensor is configured in unsupervised mode (OOK) and the low battery signaling is enabled on the control panel, the information is sent during tripping.

  • Page 12: Ivp 4000 Smart Sensor Operating Mode Setting

    11.2. IVP 4000 smart sensor operating mode setting Through jumper ECO/CONT (JP2), select between intelligent continuous mode and economic mode. Factory default: economy mode. With jumper JP2 in position 2 (ECO), the sensor will operate in economic mode, working as follows: after powering up, the sensor will work continuously for 30 minutes so that the installer can make the sensor adjustments.

  • Page 13: Ivp 4000 Smart Sensor Monitoring Setting

    Time the sensor stays on 11.3. IVP 4000 smart sensor monitoring setting » For board version 4410030/2 or 4410030/3: to change the modulation from OOK to FSK, just remove the battery from the sensor, open the jumper OOK/FSK (JP3) and then replace the battery in its original position. Feito isso o sensor will start to operate in FSK mode.

  • Page 14: Homologation

    12. Homologation 0912-14-0160 This equipment is not intended for protection against harmful interference and may not cause interference in duly authorized systems. This is a product approved by Anatel, the approval number can be found on the product label, for inquiries access the site: https://www.gov.br/anatel/pt-br.

  • Page 15: Warranty Term

    8. After its useful life, the product must be delivered to an authorized Intelbras service center or directly disposed of in an environmentally appropriate manner to avoid environmental and health impacts. If you prefer, the battery, as well as other unused Intelbras brand electronics, can be disposed of at any Green Eletron collection point (waste management facility to which we are associated).
  • Page 16 Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 124, nº 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 01.23 CNPJ 82.901.000/0016-03 –...
