Summary of Contents for Intelbras IVP 3021 SHIELD
- Page 1 User manual IVP 3021 SHIELD...
- Page 2 Congratulations, you have just purchased a product with Intelbras quality and safety. The passive infrared sensor IVP 3021 SHIELD was developed by Intelbras with 100% digital technology. The sensor has a shield that makes it safer in noisy environments and with high RFI / EMI indexes, it also has the Temperature sensor to offer the same detection sensitivity in a wide temperature range (from -10 °...
- Page 3 » Do not install the sensor directly on windows and glass doors. » LGPD - General Law for the Protection of Personal Data: Intelbras does not access, transfer, capture, or perform any other type of treatment of personal data from this product.
- Page 4 Summary 1. Technical specifications 2. Characteristics 3. Product 4. Installation 5. Configuration Warranty term...
- Page 5 1. Technical specifications Coverage 115° wide angle Range 12 m Power 9 Vdc to 18 Vdc Consumption 9 mA at 12 Vdc Operating temperature - 10° Cto 50 °C 2. Characteristics » Micro-processed digital detection technology » 2 levels of sensitivity »...
- Page 6 Connect the power to terminal J1 (+12 V) obeying the polarity. Connect the alarm wires to terminal J2. The IVP 3021 SHIELD does not need to be installed with an articulator, as it already has a 15 ° tilt angle. Its scanning angle is 115º...
- Page 7 8. After its useful life, the product must be delivered to an authorized Intelbras service center or directly disposed of in an environmentally appropriate manner to avoid environmental and health impacts. If you prefer, the battery, as well as other unused Intelbras brand electronics, can be disposed of at any Green Eletron collection point (waste management facility to which we are associated).
- Page 8 Support via e-mail: suporte@intelbras.com.br Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 124, 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 01.21 CNPJ 82.901.000/0016-03 –...
