Ports and Connectors
Port
5VDC-2A (Max)
USB Port
Ethernet Port
T1/E1 Port
SYNC IN & SYNC Out
LED
LED Description
PWR Turns on when power is supplied.
STS Blinks to indicate health of the system.
L1 Indicates the status of layer 1 of the T1/E1 line.
L2 Indicates the status of layer 2 of the T1/E1 line.
Indicates the status of the SIP Trunk to which the LED is
SIP
assigned.
2
Description
Connector for the Power Adapter.
Unused
Ethernet port can be used as
• LAN interface to connect a computer/LAN Switch.
• WAN interface to connect to IP network. You can connect a DSL modem/
Router or a LAN Switch.
T1/E1 Port to connect the T1 or E1 line.
SYNC IN and SYNC Out Ports for synchronizing the system's clock with that of
the Public ISDN Network.
