If you are mounting the system on a wall, you may refer to the mechanical dimensions of the
product and use the mounting template for drilling holes on the wall.

Connecting SETU VTEP

Connecting to the VoIP Network
Before you connect the system to WAN, we recommend that you first connect a computer to the
Ethernet Port of SETU VTEP , configure the Basic Settings, and then connect to WAN.
Use the Ethernet cable supplied for the Ethernet Port of SETU VTEP to connect the system to the
IP network, which may be Public Internet or a LAN.
If connecting to the Public IP Network,
• Plug one end of the RJ45 Ethernet cable into the Ethernet Port of SETU VTEP and the other
end into the Broadband Router/Modem.
