Bill Of Materials - Analog Devices EVAL-AD5675SDZ User Manual

UG-815

BILL OF MATERIALS

Table 4.
Qty Reference Designator
4 C1, C3, C5, C9
1 C16 2
6 C2, C4, C6, C10 to C12
1 C15 2
2 C7-C8
7 C13, C17 to C23
1 C14
9 EXT_REF, VOUT0 to VOUT7
3 J1-J3
1 J4
1 J5
1 L1
4 LK1-LK4
4 R1, R3,R5, R6
10 R2, R8-R15
1 R4
1 R7
1 R8
9 TP0-TP8
1 U1
1 U2
1 U3
1 U4
1 U5 2
1 Screw1, Screw2
2 Nut1, Nut2
1 FEC is Farnell Electronics Components
2 Not populated on EVAL-AD5675RSDZ
Populated on EVAL-AD5675RSDZ
3
4 Populated on EVAL-AD5675SDZ
Description
Capacitor, Case A, 10 µF, 10 V
Capacitor, Case A, 10 µF, 10 V
Capacitor, 100 nF, 50 V, 0603
Capacitor, 100 nF, 50 V, 0603
Capacitor, 2.2 µF, 10 V, 0603
Do not insert
Capacitor, 0603, 1 µF, 10 V
Straight PCB mount SMB jack, 50 Ω
2-pin terminal block (5 mm pitch)
120-way female connector, 0.6 mm pitch
8-pin (2x4), 0.1" pitch SMT header
Ferrite bead
Jumper block using 3-pin SIP header (insert in Position A)
SMD resistor
Do not insert
Resistor, 0805 0R0
Resistor, 1R5, 5%, 0.063 W, 0603
Do not insert
Red test point
32k I 2 C serial EEPROM
Linear regulator, 5.0 V, ultralow noise, CMOS
Linear regulator, 5 V, 20 V, 500 mA, ultralow noise, CMOS
16-bit DAC
Ultralow noise XFET voltage references
Screw, cheese, nylon, M3X10, PK100
Nut/washer, nylon, M3, PK100
Rev. A | Page 12 of 13
Evaluation Board User Guide
Supplier/Part Number
FEC 197-130
FEC 197-130
FEC 8820023
FEC 8820023
FEC 1797012
Do not insert
FEC 318-8840
FEC 1206013
FEC 151789
FEC 1324660 or Digikey H1219-ND
FEC 1022244 (36-pin strip)
Digikey 490-1024-1-ND
FEC 1022248 and 150410
FEC 9330402
Do not insert
FEC 9333681
FEC 9331832
Do not insert
FEC 8731144 (pack)
FEC 1331330
ADP7118ACPZN-5.0-R7
ADP7104ARDZ-5.0-R7
AD5675RARUZ 3
ADR431BRZ
FEC 7070597
FEC 7061857
1
or AD5675ARUZ 4
