ORDERING INFORMATION

EVALUATION BOARD BILL OF MATERIALS

Table 4. Bill of Materials
Reference Designator
C1, C9, C19, C22, C23, C25, C30
C2, C20, C29
C3, C4
C5, C6, C7, C8
C10, C21
C11, C18
C14
C24, C26
C28
D2
P3
R3, R4, R6
R7 to R10, R15, R20, R29, R45
R11 to R14, R24
R30, R31, R36 to R38
R42
R43
R44, R47, R48, R51 to R53
U1
U2
U3
U6
P1
P2
R1
R2, R5
R25 to R27, R32, R39, R46, R49, R50 0 Ω resistors, 1/10 W, 0603, DNI
R28, R33 to R35, R40, R41
analog.com
Description
0.1 μF capacitors, 16 V, 10%, X7R, 0603
10 μF capacitors, 6.3 V, 20%, 0805
5600 pF capacitors, 50 V, 10%, X7R, 0603
0.01 μF capacitors, 50 V, 10%, X8R, 0603
0.47 μF capacitors, 25 V, 10%, X8R, 0603
1 μF capacitors, 16 V, 10%, X7R, 0603
0.022 μF capacitor, 25 V, 10%, X7R, 0402
10 μF capacitors, 6.3 V, 20%, X5R, 0603
10 μF capacitor, 16 V, 10%, X5R, 0805
Schottky diode, DO41A
SDP connector
100 kΩ resistors, 1%, 1/10 W, 0603
0 Ω resistors, 1/10 W, 0603
200 kΩ resistors, 1%, 1/10 W, 0603
0 Ω resistors, 1/16 W, 0402
56 kΩ resistor, 1%, 1/10 W, 0603
150 kΩ resistor, 1%, 1/10 W, 0603
10 kΩ resistors, 1%, 1/10 W, 0603
Differential/single-ended input, dual, simultaneous
sampling, 2 MSPS, 12-bit, 3-channel SAR ADC
2
I C EEPROM, 32 kb, 8-lead SOIC
20 V, 500 mA, low noise, CMOS low dropout (LDO)
regulator
Integrated AMR angle sensor and signal conditioner
with differential outputs
8-pin connector (2.54 mm pitch), do not install (DNI)
10-pin connector (2.54 mm pitch), DNI
10 kΩ resistor, 1%, 1/10 W, 0603, DNI
100 kΩ resistors, 1%, 1/10 W, 0603, DNI
0 Ω resistors, 1/16 W, 0402, DNI
EVAL-ADA4570
Manufacturer
Kemet
Taiyo Yuden
Samsung
TDK
Murata
AVX
Samsung
Murata
Murata
Vishay
HRS
Vishay
Yageo
Panasonic
Stackpole Electronics, Inc.
Panasonic
Panasonic
Panasonic
Analog Devices
Microchip Technology
Analog Devices
Analog Devices
Samtec
Samtec
Panasonic
Vishay
Yageo
Stackpole Electronics, Inc.
Part Number
C0603C104K4RAC
JMK212BJ106MG-T
CL10B562KB8NNNC
CGA3E2X8R1H103K080AA
GCG188R91E474K
0603YC105KAT2A
CL05B223KA5NNNC
GRM188R60J106ME47D
GRM21BR61C106KE15L
1N5818-E3
FX8-120S-SV(21)
CRCW0603100KFKEA
RC0603JR-070RL
ERJ-3EKF2003V
RMCF0402ZT0R00
ERJ-3EKF5602V
ERJ-3EKF1503V
ERJ-3EKF1002V
AD7266BSUZ
24LC32A/SN
ADP7104ARDZ-R7
ADA4570BRZ
TSW-108-08-G-S
TSW-110-18-T-S
ERJ-3EKF1002V
CRCW0603100KFKEA
RC0603JR-070RL
RMCF0402ZT0R00
