Ordering Information; Bill Of Materials - Analog Devices EVAL-ADAU1772Z User Manual

Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty. Designator
17 C6 to C7, C9, C11 to C14,
C20 to C22, C25, C28 to
C30, C32, C47 to C48
8 R9, R11 to R13, R42, R48,
R53 to R54
1 C24
1 C39
2 R30, R31
1 R3
1 R1
13 R18, R23 to R25, R32 to R40
1 C23
11 C16 to C19, C26 to C27, C31,
C35 to C36, C41 to C42
1 R26
1 R28
1 R10
3 C34, C37, C40
1 L1
2 C3, C5
3 R44 to R45, R50
2 R14 to R15
5 R4 to R8
1 R27
2 C44 to C45
4 C1 to C2, C8, C10
6 R41, R47, R52, R55 to R57
1 R29
1 S7
1 Y1
1 U1
1 U4
1 U3
1 J1
1 J9
1 J4
6 J8, J10 to J12, J15, J17
2 J3, J14
1 D1
1 U2
2 D2 to D3
6 J18 to J23
10 R16 to R17, R19 to R22,
R43, R46, R49, R51
1 R2
6 C4, C15, C33, C38, C43, C46
Description
0.10 µF multilayer ceramic, 16 V, X7R (0402)
0 Ω chip resistor, 5%, 63 mW, thick film, 0402
1.0 µF multilayer ceramic, 16 V, X7R (0603)
1.0 µF multilayer ceramic, 16 V, X7R (0603)
100 Ω chip resistor, 1%, 63 mW, thick film, 0402
100 Ω chip resistor, 1%, 100 mW, thick film, 0603
100 Ω chip resistor, 1%, 125 mW, thick film, 0805
10 kΩ chip resistor, 1%, 63 mW, thick film, 0402
10 nF multilayer ceramic, 25 V, NP0 (0603)
10 µF multilayer ceramic, 10 V, X7R (0805 )
137 kΩ chip resistor, 1%, 63 mW, thick film, 0402
162 kΩ chip resistor, 1%, 63 mW, thick film, 0402
1.00 kΩ chip resistor, 1%, 63 mW, thick film, 0402
2.2 µF multilayer ceramic, 10 V, X7R (0603)
2.2 µH inductor
22 pF multilayer ceramic, 50 V, NP0 (0402)
2.00 kΩ chip resistor, 1%, 63 mW, thick film, 0402
2.67 kΩ chip resistor, 1%, 63 mW, thick film, 0402
33.2 Ω chip resistor, 1%, 63 mW, thick film, 0402
374 kΩ chip resistor, 1%, 63 mW, thick film, 0402
470 µF SMD tantalum capacitor, SMD D, 6.3 V
47.0 µF ceramic capacitor, 6.3 V, X7R, 1210
49.9 kΩ chip resistor, 1%, 63 mW, thick film, 0402
49.9 kΩ chip resistor, 1%, 63 mW, thick film, 0402
4PDT slide switch vertical break-before-make
12.288 MHz crystal, SMT, 18 pF
Four ADC, two DAC ANC Codec
Synchronous boost dc-to-dc converter
Fixed low dropout voltage regulator
10-way shroud polarized header, 2 × 5
10-way unshrouded jumper, 2 × 6
12-way unshrouded jumper
2-pin header, unshrouded jumper, 0.10";
use shunt Tyco 881545-2
3-position SIP header
Green diffused, 10 millicandela, 565 nm, 1206,
32K, I 2 C CMOS serial EEPROM
Schottky, 30 V, 0.5 A, SOD123 diode
Stereo mini jack
Do not stuff
Do not stuff
Do not stuff
Rev. A | Page 25 of 28
Part Number
ECJ-0EX1C104K
ERJ-2GE0R00X
GRM188R71C105KA12D
EMK107BJ105KA-TR
MCR01MZPF1000
ERJ-3EKF1000V
ERJ-6ENF1000V
MCR01MZPF1002
C1608C0G1E103J
GRM21BR71A106KE51L
ERJ-2RKF1373X
ERJ-2RKF1623X
ERJ-2RKF1001X
GRM188R71A225KE15D
LQH32PN2R2NN0L
GRM1555C1H220JZ01D
ERJ-2RKF2001X
CRCW04022K67FKED
RMCF0402FT33R2
ERJ-2RKF3743X
TR3D477M6R3C0200
GCM32ER70J476KE19L
CRCW040249K9FKED
MCR01MZPF49R9
ASE4204
ABM3B-12.288MHZ-10-1-U-T
ADAU1772
ADP1607ACPZ-R7
ADP1713AUJZ-1.5-R7
N2510-6002RB
PBC05DAAN or
cut PBC36DAAN
PBC06DAAN or
cut PBC36DAAN
PBC02SAAN; or
cut PBC36SAAN
PBC03SAAN; or
cut PBC36SAAN
SML-LX1206GW-TR
M24C32-F
MBR0530T1G
SJ-3523-SMT
Open
Open
Open
UG-477
Manufacturer
Panasonic EC
Panasonic EC
Murata ENA
Taiyo Yuden
Rohm
Panasonic EC
Panasonic EC
Rohm
TDK Corporation
Murata ENA
Panasonic ECG
Panasonic ECG
Panasonic EC
Murata ENA
Murata Electronics
Murata ENC
Panasonic EC
Vishay/Dale
Stackpole
Panasonic ECG
Vishay/Sprague
Murata
Vishay/Dale
Rohm
Tyco Electronics
Abracon Corporation
Analog Devices
Analog Devices
Analog Devices
3M
Sullins Connector
Solutions
Sullins Connector
Solutions
Sullins Connector
Solutions
Sullins Connector
Solutions
Lumex Opto
STMicroelectronics
On Semiconductor
CUI, Inc.
Do not stuff
Do not stuff
Do not stuff
