Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 7. Motherboard
Qty Reference Designator
3 BUF-3, BUF-4, BUF-W1
3 A6, A7, A8
5 A5, A9, A10, A11, A12
1 J1
2 J7, J8
1 J4
1 J10
1 J5
2 J2, J3
17 R1, R3, R6, R7, R8, R9, R10, R11,
R12, R13, R20, R22, R23, R34,
R35, R42, R43
1 R2
1 R41
1 R21
1 R38
1 R14
1 R4
3 R5, R25, R26
5 R15, R16, R17, R18, R19
1 C1
8 C4, C9, C10, C11, C12, C17, C19, C21
4 C2, C6, C7, C14
2 C8, C13
4 C18, C20, C22, C5
2 C3, C15
1 C16
1 C34
1 L2
1 D1
1 U1
1 U2
1 U3
1 U4
1 U5
18 /LRDAC, /RESET, /SYNC, /WP, A1,
A2, A3, A4, AGND, B1, VOUT_C1,
VOUT_C2, VOUT3, VOUT4, W1, W2,
W3, W4
5 +3V3, +5V, VDD, VLOGIC, VSS
1 FEC refers to Farnell Electronic Component Distributors; Digi-Key refers to Digi-Key Corporation.
Description
2-pin (0.1" pitch) header and shorting shunt
3-pin SIL header and shorting link
6-pin (3 × 2) 0.1" header and shorting block
3-pin terminal block (5 mm pitch)
4-pin SIL header
Receptacle, 0.6 mm, 120-way
8-pin inline header; 100 mil centers
12pin (2 × 6) 0.1" pitch header
2-pin terminal block (5 mm pitch)
SMD resistor 0 Ω, 0.01, 0603
SMD resistor 2.2 kΩ, 0.01, 0603
SMD resistor 1.7 kΩ, 1% ,0603
Resistor, surge, 1.6 Ω, 1%, 0603
SMD resistor, 2.7 kΩ, 1%, 0603
SMD resistor 100 Ω, 1%, 0603
SMD resistor 1 kΩ, 0.01, 0603
SMD resistor 100 kΩ, 1%, 0603
SMD resistor 33 kΩ, 1%, 0603
SMD capacitor, 100 nF, 10%, 0805
SMD capacitor, 0.1 µF, ±10%, 0603
SMD capacitor, 0.1 µF, ±10%, 0603
SMD capacitor,10 µF, ±10%
Capacitor 10 µF, ±20%
Capacitor 470 nF, ±10%,0603
Capacitor 4.7 nF, ±10%,0603
Capacitor 4.7 nF, ±20%
Inductor, SMD, 600Z
Green SMD LED
2 port level translating bus switch
Dual op amp
Precision low dropout voltage regulator
Operational amplifier
I 2 C serial EEPROM 64K 2.5 V MSOP-8
Terminal, PCB, black, PK100, test point
Terminal, PCB, red, PK100
Rev. 0 | Page 15 of 16
UG-397
Supplier 1 /Part Number
FEC 1022247 and FEC 150-411
FEC 1022248 and FEC 150410
FEC 148-535 and FEC 150-411
(36-pin strip)
FEC 151790
FEC 1098035
Digi-Key H1219-ND
FEC 1098038
FEC 1098051
FEC 151789
FEC 9331662
FEC 1750676
FEC 1170811
FEC 1627674
FEC 1750678
FEC 9330364
FEC 9330380
FEC 9330402
FEC 9331034
FEC 165-0863
FEC 1759122
FEC 301-9482
FEC 197-130
FEC 1190107
FEC 1414037
FEC 1414642
FEC 1432350
FEC 9526862
FEC 5790852
ADG3247BCPZ
AD8652ARZ
ADP3303ARZ-3.3
AD8618ARZ
FEC 1331335
FEC 8731128
FEC 8731144
