SOLTEK 85DRV4-C Manual page 32

85DRV4-C
2-9.9 CD-ROM Audio Connectors (CD 1)
CD 1 is an audio connector connecting CD-ROM audio to mainboard.
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
USB0
(on top)
USB1 (underside)
Main Power
Connector
Peripheral Power
AGP 4X/2X
Connector
1
CD1
AC'97
Codec
Audio Codec
WOL1
1
RT1
VIA
P4x266E
PCI 1
PCI 2
VIA
PCI 3
VT8233A
1
JP1
PCI 4
1
JBAT1
RT2
PCI 5
1
FAN3
IT8705F
LPC I/O
SCR1
FLASH BIOS
10
14
JUSB1
1
1
CD-ROM Audio Connector
CD 1 Pin 1 Pin 2
Left
1
Channel GND
36
Pin 3 Pin 4
Right
GND Channel
