2-9.7 Thermal Sensor Connectors RT1 and RT2
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
USB0
(on top)
USB1 (underside)
Main Power
Connector
Peripheral Power
AGP 4X/2X
Connector
1
CD1
AC'97
Codec
Audio Codec
WOL1
1
1. Connector RT1: A thermal resistor will be mounted by default to
connector RT1 so as to detect the temperature of the CPU. What
RT1 does is to transmit the thermal signal to BIOS or Hardware
Monitor.
2. Connector RT2: A thermal cable is needed to connect RT2 to on-
board devices such as HDD, Graphics card etc., so as to detect the
temperature generated therein. Please connect the end (a) of the
thermal cable to RT2, and tape another end (b) of thermal cable on
to the device which you want to monitor. After you have finished the
thermal cable installation, you will see the detected temperature in
BIOS setup or Hardware Monitor utility.
RT1
VIA
P4x266E
PCI 1
PCI 2
PCI 3
VIA
VT8233A
1
JP1
PCI 4
1
JBAT1
RT2
PCI 5
1
FAN3
IT8705F
LPC I/O
SCR1
FLASH BIOS
10
14
JUSB1
1
1
33
Chapter 2 Hardware Setup
RT1
RT1 will be mounted
with Thermal Resistor
by default.
RT2
To Devices
To RT2
Thermal Cable
(Optional)
