85DRV4-C
2-9.8 Complex Pin-header (Front Panel Connector)
This complex Pin-header consists of the following connectors for vari-
ous supports. When you have fixed the mainboard to the case, join the
connectors of this Complex Pin-header to the case Front Panel.
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
USB0
(on top)
USB1 (underside)
Main Power
Connector
VIA
P4x266E
Peripheral Power
AGP 4X/2X
Connector
PCI 1
1
CD1
PCI 2
PCI 3
AC'97
Codec
Audio Codec
PCI 4
PCI 5
JUSB1
WOL1
1
1
Power Switch
2
3
INFRARED TRANSMIT SIGNAL
Infrared(IR)
INFRARED TRANSMIT SIGNAL
2nd HDD LED
4
1st HDD LED
RT1
VIA
VT8233A
1
JP1
1
JBAT1
RT2
1
FAN3
IT8705F
LPC I/O
SCR1
FLASH BIOS
10
14
1
GND
SMI
1
SMI SIGNAL
Vcc
ATX POWER SWITCH
Vcc
NO CONNECTION
GND
(+)
Logic High
(-)
HDD LED SIGNAL
(-)
HDD LED SIGNAL
(+)
Logic High
GND
SUSPEND LED SIGNAL
GND
Keylock
KLOCK
(-)
GND
NO CONNECTION
(+)
Vcc
GND
RESET SIGNAL
SPEAKER SIGNAL
GND
NO CONNECTION
Vcc
34
Case
Front Panel
5
Suspend LED
(Optional)
6
Power LED 7
Reset Switch
8
Speaker
9
