85DRV4-C

2-7 ATX V2.03 Power Supply Installation

+12V Power Connector
+12V
+12V
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
USB0
(on top)
USB1 (underside)
Peripheral Power
Connector
1
CD1
AC'97
Codec
Audio Codec
WOL1
1
ATX V2.03 power supply is strongly recommended for mainboard run-
ning with 2GMHz or higher CPU.
To set up Power Supply on this mainboard:
1. Connect the on-board Main Power Connector (20-pin) to the Main
Power Connector (20-pin) of an ATX Power Supply which can be
either of the latest version 2.03 or of earlier ATX model.
2. If you use an ATX Power Supply Version 2.03 or the later ones, you
can now connect the onboard square-shaped +12V Connector to the
square-shaped +12V Connector of your ATX Power Supply. In this
case, it is not necessary for you to connect the onboard 4-pin
Peripheral Power Connector to your Power Supply.
3. If you use an ATX power Supply of an older version than V2.03, there
will be no square-shaped +12V Connector. So please connect the
onboard 4-pin Peripheral Power Connector to the 4-pin Peripheral
Power Connector of your Power Supply.
3 1
GND
GND
4
2
RT1
Main Power
Connector
VIA
P4x266E
AGP 4X/2X
PCI 1
PCI 2
PCI 3 VIA
VT8233A
1
JP1
PCI 4
1
JBAT1
RT2
PCI 5
1
FAN3
IT8705F
LPC I/O
SCR1
FLASH BIOS
10
14
JUSB1
1
1
Pin1
+12V
5SB
PWR_OK
GND
+5V
GND
+5V
GND
+3.3V
+3.3V
Main Power Connector
(20-pin)
Pin 1
Pin 4
Peripheral
Power Connector
24
Pin11
+5V
+5V
-5V
GND
GND
GND
PS_ON#
GND
-12V
+3.3V
+12V
GND
GND
+5V
