Jp1:
CPU Clock Select
1
1-2 closed (default)
CPU Auto-detect
of
100 / 133MHz
1
Jumper open
100MHz selected
1
2-3 closed
133MHz selected
Further Notes on CPU Overclocking:
1. If you have successfully booted system, with or without CPU
overclock, you still can try another CPU overclock in BIOS Setup.
Please enter BIOS Setup, choose "Frequency/Voltage Control" menu,
and take the "Use Linear" option of the "Use CPU Linear Frequency".
Then configure the "CPU Clock" item to raise your CPU clock.
2. CPU overclocking should take all components on board into account.
If you fail in BIOS overclocking, you will not be able to restart system.
In such case, Power off system and clear CMOS by JBAT1 and then
restart your system. And remember to reconfigure whatever should
be reconfigured.
3. If your system is already fixed in a cabinet or case, you may not like
to take the trouble to clear CMOS. Then power on your system with
the power button on the PC case and simultaneously press down the
"Insert" key on the keyboard until you see the initial bootup screen
appear. And remember you should also enter CMOS BIOS Setup
instantly and choose "Load Optimized Defaults" to restore default
BIOS .
SW1
Overclock setting
to Boot System
100/103/107/111SW1
setting for 100MHz
CPU to boot system;
133MHz SW1 setting
for 133MHz CPU to
boot system;
100/103/107/111 to
boot system
133MHz SW1 setting
to boot system
27
Chapter 2 Hardware Setup
Overclock Select
SW1
Off On On On
(Default)
On Off
CPU clock
S2
S1
(MHz)
100
off on
(default)
off on
103
on
107
off
off off
110
on
off
133
S4
S3
on on
on
off
on
off
on
off
on
on
