The Robin iSpiider is equipped with the QVGA screen with battery backup and four control buttons which
allow you to set the fixture´s behaviour according to your needs, obtain information on its operation, test its
various parts and program it, if it has to be used in a stand-alone mode.
The fixture supports NFC (Near-Field Communication).
NFC interface and control buttons on the front panel
[ESCAPE] button used to leave the menu without saving changes.
[NEXT] , [PREV] buttons for moving between menu items and symbols, adjusting values.
[ENTER/Display On] button used to enter the selected menu (menu item) and to confirm adjusted value.
If the fixture is disconnected from mains, the button switches the screen on.
Icons used in the screen menu:
- [back arrow] used to move back to the previous screen (menu).
- [up arrow] used to move up on the previous page.
- [down arrow] used to move down on the next page.
- [confirm] used to save adjusted values, to leave menu or to perform desired action.
- [cancel] used to leave menu item without saving changes.
- [confirm+copy] used to save adjusted values and copy them to the next prog. step.
- [warning icon] used to indicate some error which has occurred in the fixture.
- [Ethernet] used to indicate Ethernet connected.
- [display turn] used to turn the display by 180°.
- [slider control] used to recall slider system for setting desired value.
- [keyboard control] used to recall keyboard system for setting desired value.
- [air filters cleaning] used to signal that cleaning period of the air filters elapsed.
The menu page displays icons for each function that you can perform from the screen.
After switching the fixture on, the screen shows the screen with the ROBE logo:
Note: The green icon at the top right corner of the screen indicates the level of the display battery charging. If
