Robe iSpiider User Manual page 71

Version: 1.1 (10 modes)
Mode/channel
DMX
1 2 3 4
Value
1 1 1 1
0 - 255
2 2 2 2
0 - 255
3 3 3 3
0 - 255
4 4 4 4
0 - 255
5 5 5 5
2 - 255
2 - 255
6 6 6 6
0 -5
10-14
15-19
20-24
25-29
30-34
35-39
40-44
45 - 49
50 -54
55 -59
60 - 64
65 - 69
70 - 74
75 - 79
80 - 84
85 - 89
90 -109 Reserved
110-114 Kling-Net ON
DMX protocol
Robin iSpiider - DMX protocol
Mode 1 - 3-zones,
Pan (8 bit)
Pan movement by 540° (128=default)
Pan Fine (16 bit)
Fine control of pan movement (0=default)
Tilt (8 bit)
Tilt movement by 220° (128=default)
Tilt fine (16 bit)
Fine control of tilt movement (0=default)
Pan/Tilt speed , Pan/Tilt time
0 Standard mode (0=default)
1 Max. Speed Mode
Pan/Tilt speed mode
Speed from max. to min.
Pan/Tilt time mode
Time from 0.2 s to 25.5 sec.
Power/Special functions
Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe"
channel 53/27/31/31 must be at range: 0-31 DMX). Corresponding
menu items are temporarily overriden (unless otherwise stated)
Standby mode: On (fixture effects are deactivated, light output is
6
closed)
7
Standby mode: Off
Pressure test: On
8
( fixture does not respond to DMX during the test
except value 9 (Pressure test: Off))
Pressure test: Off
9
DMX input: Wired DMX
DMX input: Wireless DMX *
Graphic display On
Graphic display Off
RGBW colour mixing mode
CMY colour mixing mode
Pan/Tilt speed mode
Pan/Tilt time mode
Blackout while pan/tilt moving
Disabled blackout while pan/tilt moving
Dimmer curve-square law
Dimmer curve-linear
Fans mode: Auto
Fans mode: High
White point 8000K On
White point 8000K Off
Mode 2-Basic, Mode 3 -Advanced, Mode 4 -Full RGBW
Function
Page 1
Type of
control
proportional
proportional
proportional
proportional
step
step
proportional
proportional
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
