Misc. on the DESKLINE

This system is a DESKLINE system developed for desks and for indoor use in of-
fi ces. Do not use it in industrial kitchens or in other enviroments that have to
be cleaned with aggressive detergents.
Do not bolt the legs to the fl oor so that free movement is prevented. This could
cause serious damage to the legs in fault situations.

Warranty

There is a 36 months' warranty on the DESKLINE products against manufactur-
ing faults from the production date of the individual products (see label).
LINAK A/S' warranty is only valid in so far as the equipment has been used
and maintained correctly and has not been tampered with. Furthermore, the
system must not be exposed to violent treatment. In the event of this, the
warranty will be ineffective/invalid. For further details, please see LINAK A/S
ordinary conditions of sale.

Maintenance

Clean dust and dirt on the outside of the system at appropriate intervals and
inspect them for damage and breaks.
Inspect the connections, cables, and plugs and check for correct functioning as
well as fi xing points.
The cleaners and disinfectants must not be highly alkaline or acidic
(pH value 6-8).

Description of the DESKLINE

®
Each DESKLINE
memory drive is ensured by means of software in the CBD4/CBD5 that also
takes account of oblique load on the desk. Soft start and stop are also part of
this software, which ensures a soft start and stop when adjusting the desk.
Application of the DESKLINE
Irrespective of the load the duty cycle 10% ~ 6 min./ hour or max. 2 min. at
continuous use stated in the data sheets, must NOT be exceeded as this will
result in a superheating of the motor, the brake and the spindle nut. Exceeding
the duty cycle will result in a dramatic reduction of the life of the system.
®
The DESKLINE
• 1 control box CBD4/CBD5
• 1 single DL5/DL6 or 2, 3, or 4 parallel
• 1 exchangeable mains cable
• 1, 2, 3, or 4 motor cables
• 1 DP1U/DPF1M (if memory function is required) DP1C/WDPL/DPT/DPF1C (if
memory function and display is required) or 1 DPA/DPB/DP1K/DP1L/DP1V/
DPFK (Desk Panel without memory)
®

DL5/DL6 system

DL5/DL6 lifting units is equipped with a motor and parallel/
®
DL5/DL6 system:
DL5/DL6 system range contains the following products:
®
DL5/DL6 system
7
