Parts List - SSV Works RZ34-Q5ARC Manual

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty
against defects in material or workmanship. All Kicker Speakers are covered by a limited 1
year warranty against defects in material or workmanship. All Kicker Amplifiers are covered by
a limited 2 year warranty against defects in material or workmanship. Labor for replacement
of defective components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- T30 & T40 Torx Socket
- 10mm and 5.5mm Socket
& Rachet or Wrench
PARTS LIST IMAGES
1. Amp Power Wire x2
5. Amp Tray Base Brackets
(Depending on model)
9. Fuse Holder with 40A Fuse x2
- 4mm & 5mm Allen Wrench
- #2 & #3 Phillips Screwdriver
2. B-H1909 Front Speaker Wire
6. M6 x 1.0 Screws and
Washers x 2
10. Battery Terminal Cable x2
!
- Drill with 13/64", 1/8", 1/4"
& 1/2" Drill bits
- Panel removal tool
3. B-H1912 and B-H1913
Rear Speaker Expansion
Triangular end
7. Self-Tapping Screw and
Washer x 1
11. Connector Cover with
Relief Cut-out

PARTS LIST 1/4

Wiring Installation
Please read and understand these
instructions completely before
installation to avoid possible injury,
or damage to the accessory or vehicle.
- Wire Crimpers - Scribe or Marker
- Wire Strippers - Utility Knife
4. Amp Tray with pre-loaded
PhaseEQ Amplifier
8. Zip Ties x 10
12. B-H2346 Ride
Command harness
