These following steps are needed to ensure clearance for the sub enclosure and allow proper performance for vehicles with Polaris Dynamix.
A. Start by removing the four (4) 10mm bolts securing the Dynamix
brain tray.
C. Run a zip tie through the provided connector cover as shown in
figure C.
E. Bend harness towards zip tie and close the tie.
A
B. Tilt the brain back, unsnap the perimeter of the connector cover as it will be
replaced by the provided cover that has a cable relief cut-out.
C
D. Snap the connector housing back into place over the connector.
E
F. Cinch down zip tie as show in figure (F). Put the Dynamix brain
tray back in place but DO NOT REINSTALL THE BOLTS.
B
B
D
F
9
