A. Starting at driver side footwell, remove the factory T40 torx
screw as shown. Save this screw for Step D.
C. Using (x2) #14 screw loosely secure the kick pod to the factory
screw bosses.
E. Connect the B-H1909 cable to both passenger and driver side
speaker pods and zip tie all cables to the frame.
A
C
E
G. Repeat Steps A-F to install passenger kick pod.
B. Place the driver kick pod into location so that both vehicle
screw bosses line up with kick pod brackets.
D. Re-use the factory T40 torx screw previously removed in
Step A to loosely bolt through the lower kick pod bracket to
vehicle panel. Once all three screws are in place go back and
re-tighten.
F. Connect the B-H1909 speaker harness to the 800.5 amplifier
front output.
B
D
F
