Parts List - SSV Works RZ34-Q5A3 Installation Instructions Manual

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty
against defects in material or workmanship. All Kicker Speakers are covered by a limited 1
year warranty against defects in material or workmanship. All Kicker Amplifiers are covered by
a limited 2 year warranty against defects in material or workmanship. Labor for replacement
of defective components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- T30 & T40 Torx Socket
- 10mm and 5.5mm Socket
& Rachet or Wrench
PARTS LIST IMAGES
1. Amp Power Wire x1
5. Amp Tray Base Brackets
(Depending on model)
9. Fuse Holder with 40A Fuse x 1
- 4mm & 5mm Allen Wrench
- #2 & #3 Phillips Screwdriver
2. B-H1909 Front Speaker Wire
6. M6 x 1.0 Screws x 2
(T-30 torx)
10. Battery Terminal Cable x 1
!
- Drill with 13/64", 1/8", 1/4"
& 1/2" Drill bits
- Panel removal tool
3. B-H1912 and B-H1913
Rear Speaker Expansion
7. M6 Washers x 7
11. MRB3 Power & Ground
Connector

PARTS LIST 1/6

Wiring Installation
Please read and understand these
instructions completely before
installation to avoid possible injury,
or damage to the accessory or vehicle.
- Scribe or Marker
- Utility Knife
4. Amp Tray with pre-loaded
PhaseEQ Amp and MRB3 brain
Triangular
end
8. Thread Cutting Screw x 5
(#3 Phillips)
12. Zip Ties
