TOOLS NEEDED FOR INSTALLATION
- 5mm Allen Key
PARTS LIST IMAGES
1. US-C65 Enclosures (1 pair)
5. M6 Hex Head Bolts &
Washers x4
INSTALLATION NOTES
It is recommended to wrap the bag that the clamps come in around the cage before you slide the clamp onto the cage to prevent scratching.
- 8mm Open End Wrench
2. Dual Mounting Ring
Adapter x 2
6. M6 Allen Socket Head Bolts
& Washers x4
PARTS LIST 4/4
Kicker 6.5" Speaker Enclosures
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
Placement of the pod depends on what type of roll
cage you have (factory or aftermarket) and your
preference of where you want the pods to be installed.
In these instructions, we have installed them on the
outside vertical bars at the back of the roll cage.
3. Ring Clamp x 4
7. M6 Set Screws x 4
Cage Mount
4. Rear B-H2195 Speaker
Harness
