Labels

Max. Deceleration Dist:
Min. Fall Clearance:
WARNING: Manufacturer's instructions supplied with product must be read prior to use. Failure
to follow instructions may result in serious injury or death. Never modify product. Not repairable.
USE: Maximum 2' free fall. Anchor point must never be positioned more than 2' below harness
D-ring. Free fall decreases capacity and increases deceleration distance. Avoid lifeline contact
INSPECTION: Prior to each use, per instructions, inspect for signs of deployment, locking function
(pull sharply to test), retraction function, legibility of labels, evidence of defects, damage, or missing
parts, and condition of connectors, housing, and lifeline (inspect full length). Inspection by
7
Distributed by Engineered Fall Protection | Sales@EngineeredFallProtection.com | (314) 492-4422 | www.EngineeredFallProtection.com
Assembled in USA
GR1 1
WEB
S E L F - R E T R A C T I N G
L I F E L I N E
ANSI Z359.14-2014
& A10.32-2012
OSHA 1926 Subpart M
& 1910.140
DO NOT REMOVE LABELS
11' SELF-RETRACTING LIFELINE
Anchor Point at/above D-ring
User Weight Range: 130-310 lbs 311-420 lbs
24" 84"
5'6" 10'6"
Class A SRL
with sharp edges both during work and in event of a fall. For use by trained users only.
Maximum one user. Ensure connection to anchorage is secured properly before use.
May be used as a component of a PFAS in HLL applications.
NOT SUITABLE FOR LEADING EDGE USE
NUNCA DEBEN USARSE EN APLICACIONES DE BORDE EXPUESTO
Competent Person required at least every 12 months. Immediately remove from service
in event of failed inspection or if unit is subjected to a fall.
PART #: DOM:
32080 MM/YY
INSPECTED BY:
Date:
Date of First Use:
guardianfall.com
Anchor Point below D-ring (2' Max.)
User Weight Range: 130 - 310 lbs
Max. Deceleration Dist: 44"
Min. Fall Clearance: 9'2"
LOT #:
000000000000000
SPECIFICATIONS:
Initials:
Average Arresting
Force: 1,350 lbs.
Webbing: 11' HMPE,
13/16" width.
90951 (Rev. E)
85366 (Rev. G)
