Summary of Contents for Guardian Fall Protection GR6 Tie-Back SRL
-
Page 1: Table Of Contents
Product Name: GR6 Tie-Back SRL Part #: 32015; 32016 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations 2 - 3 Components and Specifications... -
Page 3: Introduction
Trainer: the equipment. The user must understand how to safely and effectively use the User: GR6 Tie-Back SRL, and all fall safety equipment used in combination with the GR6 Tie-Back SRL. Applicable Safety Standards When used according to instruction specifications, this product meets or exceeds all applicable OSHA 1926.502 and OSHA 1910.140 standards for fall protection. -
Page 4: Product Specific Applications
Maximum 1 attachment per connection point. Personal Fall Arrest: GR6 Tie-Back SRL may be used to support a MAXIMUM 1 PFAS for use in Fall Arrest applications. Structure must withstand loads applied in the directions permitted by the system of at least 5,000 lbs. - Page 5 All connections must be selected and deemed compatible with GR6 Tie-Back SRL by a Competent Person. All connector gates must be self-closing and self-locking, and withstand minimum loads of 3,600 lbs.
-
Page 6: Components And Specifications
Components and Specifications Materials: stainless steel, glass-filled nylon, HMPE, and galvanized steel. Average arrest force: 1,350 lbs. Maximum arrest force:1,800 lbs. Anchor point at or above D-ring: Anchor point below D-ring (max 2’): - Maximum deceleration distance: 24”. - Maximum deceleration distance: 44”. - Minimum fall clearance: 5.5’... -
Page 7: Installation And Use
3. If using dual leg GR6 Tie-Back SRL, ensure 100% tie-off will be maintained at all times; ALWAYS attach disengaged hook to a compatible anchor point prior to unhooking engaged hook. - Page 8 C) Attach GR6 Tie-Back SRL housing to harness dorsal D-ring with compatible carabiner. For dual leg unit, attach by passing bracket locking bar through web loop immediately beneath harness dorsal D-ring as shown. Ensure bracket is fully closed and locked prior to use; green indicator must be fully visible.
- Page 9 Standard: A) Attach GR6 Tie-Back SRL housing either to harness dorsal D-ring or to compatible overhead anchorage connector with compatible carabiner. To locate housing at harness, connect single leg unit to dorsal D-ring with compatible carabiner, and for dual leg unit attach by passing bracket locking bar through web loop immediately beneath harness dorsal D-ring as shown.
-
Page 10: Maintenance, Cleaning, And Storage
GR6 Tie-Back SRL before and after each use. If GR6 Tie-Back SRL cannot be cleaned with plain water, use mild soap and water, then rinse and wipe dry. NEVER clean GR6 Tie-Back SRL with corrosive substances. -
Page 11: Safety Information
Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment. -
Page 12: Labels
Labels Assembled in USA GR6 TIE-BACK S E L F - R E T R A C T I N G L I F E L I N E Anchor Point at/above D-ring Anchor Point below D-ring (2’ Max.) User Weight Range: 130 - 420 lbs. User Weight Range: 130 - 310 lbs.
