I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Gas Target Top Range Electric Ovens RN8110GE RNB8110GE RNL8110GE RNLB8110GE RN8110GEC...
Page 2
MANUFACTURED BY Moffat Limited Rolleston 7675 New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315...
Contents Waldorf Gas Target Top Range Electric Ovens RN(L)(B)8110GE Gas Target Top Range Electric Static Oven. RN(L)(B)8110GEC Gas Target Top Range Electric Convection Oven. Introduction ....................2 Specification ....................3 Model Numbers Covered in this Specification General Gas Supply Requirements...
Introduction We are confident that you will be delighted with your WALDORF Gas Target Top Range Electric Oven, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf appliance, there are two important things you can do.
Specifications Model Numbers Covered in this Specification RN[1]8110GE Gas Target Top Range Electric Static Oven - 900 mm. RN[1]8110GEC Gas Target Top Range Electric Convection Oven - 900 mm. NOTE: [1]: - Model Options; - Standard. - Low Back. - Bold Front. - Low Back and Bold Front.
Waldorf Target Top Range Electric Ovens are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation.
Installation Components having adjustments protected (e.g. paint sealed) by manufacturer are only to be adjusted by an authorised service agent. They are not to be adjusted by the installation person. NOTE: Do not obstruct or block appliances flue. Never directly connect a ventilation system to appliance flue outlet.
Installation Gas Connection NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN QUALIFIED SERVICE PERSON. It is essential that gas supply is correct for appliance to be installed and that adequate supply pressure and volume are available. The following checks should be made before installation:- a.
Installation Electrical Connection Warning HIS APPLIANCE MUST BE EARTHED F SUPPLY CORD IS DAMAGED IT MUST BE REPLACED BY A SUITABLY QUALIFIED PERSON IN ORDER TO AVOID A HAZARD NOTE: ALL ELECTRICAL CONNECTIONS MUST ONLY BE CARRIED OUT BY A QUALIFIED PERSON.
Installation Commissioning Before leaving the new installation; a. Check the following functions in accordance with operating instructions specified in ‘Operation’ section of this manual. Light the Target Top Pilot Burner. Light the Target Top Main Burner. Check the Target Top Low Fire Burner operation. ...
/ operator. Waldorf appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product.
Operation Lighting Pilot Burner (Target Top) Remove centre casting with casting removal tool. Depress control knob and rotate anti-clockwise to ‘PILOT’ position. With control knob depressed, manually light pilot burner located in front of main burner. Hold in control knob for approximately 10 to 15 seconds, then release. Pilot burner should remain alight.
Operation Oven ! IMPORTANT DO NOT USE aluminium foil or trays directly on cast iron sole plate(s). NEVER block or cover openings on each side of sole plate(s). The oven is fitted with top and bottom elements. The thermostat maintains overall oven temperature.
Cleaning and Maintenance General Caution Always turn off the electrical and gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. Clean the Target Top / Range regularly. A clean appliance looks better, will last longer and will perform better.
Cleaning and Maintenance Target Top a. This should be kept clean of any build up of spillage’s of food. Provided cast iron work surface is regularly used it will maintain itself in good condition with no special cleaning required. b. Clean food residue and spillage from channels around centre casting and main plates before use. c.
Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers most common problems reported, you may encounter a problem not covered in this section.
Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas and electrical supplies before commencing servicing. NOTE: These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning appliance. ...
Page 25
Gas Conversion and Specifications NOTE: Ensure pilot burner and thermocouple are correctly located and pilot burner aligns Pilot Burner Main Burner with main burner ignition port. (Refer to Ignition Port Thermocouple figure opposite for correct fitting and 2± 2.0 alignment dimensions). 18±...
Page 26
Gas Conversion and Specifications Gas Regulator NOTE, Pin rotated - NAT Gas / LPG / Butane Only. for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet NOTE, Pin rotated pressure is fixed ex-factory and for LPG is NOT to be adjusted.
Gas Conversion and Specifications Gas Specifications - Australia: Natural Gas LP Gas (Propane) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 1.10mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 1.55mm Pilot Burner Injector 0.35 0.25 Burner Aeration Screw X (Inner) 25mm 25mm Burner Aeration Screw Y (Outer)
Page 28
Gas Conversion and Specifications - UK Only: Category: 2H3P. Flue Type: Natural Gas (G20) Propane (G31) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 1.10mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 1.55mm Pilot Burner Injector 0.35 0.25 Burner Aeration Screw X (Inner) 25mm 20mm Burner Aeration Screw Y (Outer)
Page 29
Gas Conversion and Specifications - All Other Markets: Natural Gas Town Gas (**) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 4.20mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 6.30mm Pilot Injector 0.35 0.70 Burner Aeration Screw X (Inner) 25mm 20mm Burner Aeration Screw Y (Outer)
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for servicing and repair of this appliance. Instructions supplied with parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on reverse of front cover of this manual).
Page 31
Replacement Parts List General 227012 Centre Casting. 227013 Half Plate Casting. 014997 Casting Removal Tool. 227892 Side Rack LH. 227893 Side Rack RH. 227896 Oven Rack. 228571 Index Mark Moulding. 227963 Neon Orange. 227962 Neon Green. 227850 Leg (150 mm) Adjustable. 229674 Rear Roller Assy.
