Figure 10. 5V Jumper Selection Jp3[3-4]: Vin_5V Power Source - ST STM32U5 Nucleo-64 User Manual

VIN (VIN_5V) is the 7 to 12 V DC power source from the ARDUINO
the ST morpho connector (CN7) pin 24. The 5V jumper selection (JP3) must be on pin [3‑4] to select VIN_5V
power source. In that case, the DC power can come from the ARDUINO
Adafruit PowerBoost 500 shield).
An LDO (U16) is used to provide a fixed 5 V from VIN (7-12V).
VIN_5V configuration: 5V jumper selection (JP3) [3-4] must be connected as shown in
ST morpho connector
®
ARDUINO Power connector
UM3062 - Rev 1
Figure 10. 5V jumper selection JP3[3-4]: VIN_5V power source
(CN7 – Pin 24)
(CN6 – Pin 8)
Power supply and power selection
®
connector (CN6) pin 8 (VIN), or from
®
Uno V3 battery shield (compatible with
Figure
STM32
microcontroller
UM3062
10.
5V LED
(LD3)
VIN/VIN_5V
selection
(JP3 [3-4])
page 19/45
