Javad TRIUMPH-2 Manual page 4

Standard Cabling
Radio
HPT901BT
HPT401BT
HPT404BT
HPT435BT
Alternative Cabling*
HPT901BT
HPT401BT
HPT404BT
HPT435BT
*Available for purchase from our website:
http://www.javad.com/jgnss/products/accessories/
Step 3. If you have previously installed the USB drivers, Run
NetView and connect to the TRIUMPH‐2 before skipping
ahead to Step 4; otherwise proceed with the completion of
Step 3.
The very first time that your TRIUMPH‐2 is connected to your
PC using a USB port and powered on, your Windows operat-
ing system will likely begin automatically searching for the
drivers and then prompt you indicating that the drivers will
need to be installed.
4
Cable
[14-578110-02] for Data-
Ser-Pwr Cable, DB9/DB15/
SAE (6 ft / 1,8m)
[14-578110-01] for Da-
ta-Ser Cable, DB9/DB15 (6
ft / 1,8m)
[14-578123-02] for Data-
USB-Pwr Cable, USB/DB15/
SAE (6 ft / 1,8m)
[14-578123-01] for Da-
ta-USB Cable, USB/DB15 (6
ft / 1,8m)
Pairing the Radio
Click Close
Procedure for Driver Installation
Once installed, the drivers will allow your operating system
to create a virtual serial port whenever you've connected
your TRIUMPH‐2 to your PC via USB.
The USB drivers for the TRIUMPH‐2 can be downloaded from
our website: http://www.javad.com/jgnss/support/update.html;
scroll down the page and download
Extract the files into an easy to find folder; e.g.:
F:\Jobs\JAVAD\Software\Drivers\jgnssusb
jgnssusb.zip
