The MinPad is the receiver's minimum interface used to display and control data
input and output.
Function Symbol
BATTERY
1
WLAN
SATELLITES
2
POSITION
RECORDING
3
1.Blinking every 1 sec according to the battery means receiver is ON without external power. LED solid according to the battery means
external power is connected.
2. Effective number of satellites are total number of satellites tracked minus the number of non-GPS systems tracked. For example if
8 GPS and 5 GLONASS are tracked the effective number of satellites is 12.
3. RECORDING LED blinks on each recording.
Function Symbol
BLUETOOTH
14

Appendix A - Blinking LEDs

To turn ON the receiver press the power button. To turn OFF the receiver, press and hold
the power button until LEDs are off and then release the button.
Green Yellow
Full Half
Connected Initialization
8 or more 5 to 7
Fixed/Diff/
Float/No-Diff
OK (Base)
Less than 10
Recording min memory left Memory Full
Blue Yellow
Connected Searching
Appendix A - Blinking LEDs Explained

Start Guide

Appendices
Red OFF
Almost empty OFF/No power
Error Not Active
Less than 5 No Satellite
No Position Receiver OFF
Not Active
Red OFF
No connection Not Active
The record
starts/stops data
recording.
Power port is used to connect
the receiver to an external power
source and to charge the batteries.
Input voltage: +10...16 VDC.
USB port is used for high-speed
data transfer and communication be-
tween the receiver and an external
device.
Revision 1.3 from May 28, 2014
button
