Absolute Maximum Ratings; Thermal Resistance; Esd Caution - Analog Devices AD7195 Manual

AD7195

ABSOLUTE MAXIMUM RATINGS

T = 25°C, unless otherwise noted.
A
Table 3.
Parameter
AV to AGND
DD
DV to AGND
DD
AGND to DGND
Analog Input Voltage to AGND
Reference Input Voltage to AGND
Digital Input Voltage to DGND
Digital Output Voltage to DGND
AIN/Digital Input Current
Operating Temperature Range
Storage Temperature Range
Maximum Junction Temperature
Lead Temperature, Soldering
Reflow
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
Downloaded from Elcodis.com electronic components distributor
Rating
−0.3 V to +6.5 V
−0.3 V to +6.5 V
−0.3 V to +0.3 V
−0.3 V to AV + 0.3 V
DD
−0.3 V to AV
+ 0.3 V
DD
−0.3 V to DV + 0.3 V
DD
−0.3 V to DV + 0.3 V
DD
10 mA
−40°C to +105°C
−65°C to +150°C
150°C
260°C
Rev. 0 | Page 8 of 44

THERMAL RESISTANCE

θ is specified for the worst-case conditions, that is, a device
JA
soldered in a circuit board for surface-mount packages.
Table 4. Thermal Resistance
Package Type
32-Lead LFCSP_WQ

ESD CAUTION

θ θ Unit
JA JC
32.5 32.71 °C/W
