SECTION: 3. SYSTEM SETUP
3.1 REAR VIEW
2
3.1.1 RAPID
UI Cable
Mains Power
Switch
Fuse Access
and Voltage
Selector
Power Entry
Module
10A Link
Lead
HV Cable
The MAGSTIM Company LTD
8
MOP03-EN-01
Isolated
Trigger Port
Foot Switch
Pneumatic
Socket
Cooling Fan
Outlet
HV Power
Entry Socket
Earth Strap
June 2011
