ADP5350-EVALZ User Guide
USING ADP5350 GUI SOFTWARE

OPERATING THE BOARD WITH THE GUI

Before running the software,
1. Ensure that the Analog Devices USB to I
USB-SDP-CABLEZ, is plugged into the USB port of
the computer.
2. Connect a 5 V power supply between the VBUS and GND
screw terminals or connect a charged battery between
ISOB and GND (see Figure 16).
3. Click Start > All Programs > ADP5350GUI 1v0 >
ADP5350GUI.
The software is then ready to use, as shown in Figure 11. The
GUI automatically reads the content of the registers and
updates the status of the registers in real time, after the last
action.
2 C dongle,
GUI Software, Charge Control Tab
Figure 11. ADP5350
Rev. A | Page 5 of 17

BASIC CHARGING PARAMETER SETTINGS

After the input power supply is connected and is between 4.0 V
and 5.38 V, the ADP5350 begins charging. If the resistance in
the THR input corresponds to a battery temperature of between
0°C and 60°C (or to the temperature programmed from I
and the battery detection indicates that the battery is connected
at the ISOB and BSNS inputs, the
mode.
Charging begins with the default operational parameter settings
when EN_CHG is set high. The options under Charge Parameter
Control on the left side of the Charge Control tab can also be
selected before the ADP5350
The Charge Control tab includes other options, including
Function Setting, Timer Setting, Battery Thermistor Control,
and Interrupt Setting. The statuses of the charger and battery,
fault status, and power-good settings are also indicated on this
tab. In addition, when an interrupt occurs, the Interrupt
Message indication blinks for 5 sec.
UG-1104
2
ADP5350 enters charging
charges.
C)
