The means for the fields for "Ethernet" are:
In the field "IP Address", insert the IP address that you want to give to the converter;
In the field "SubNet Mask" insert the SubNet Mask;
In the field "Port" insert the number of the port;
In the field "Gateway", insert the default gateway that you want to use. This feature can be enabled or disabled pressing the Check
Box field. This feature is used for going out of the net;
In the field "Protocol" the Ethernet protocol used by the converter is defined (TCP or UDP).
