Securing the Handbrakes

1.12
YOU WILL NEED THE 5MM ALLEN KEY.
1. LOOSEN THE SCREW ON THE LEFT HANDBRAKE CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1 – 2 ROTATIONS
WITH THE 5MM ALLEN KEY.
2. ROTATE THE HANDBRAKE CLAMP AROUND THE HANDLEBAR UNTIL THE HANDBRAKE LEVER IN A POSITION AT WHICH
CAN EASILY BE REACHED BY THE RIDER WHEN HOLDING ONTO THE HANDLEBAR.
3. WHILE HOLDING THE HANDBRAKE IN THE DESIRED POSITION, TIGHTEN THE SCREW ON THE CLAMP BY TURNING IT
CLOCKWISE WITH THE ALLEN KEY.
4. REPEAT STEPS 1 - 3 ON THE RIGHT HANDBRAKE CLAMP.
LEFT HANDBRAKE
40
5MM ALLEN KEY
HANDBRAKE CLAMP
