Jetson Zephyr Manual page 20

3. LOOSEN AND REMOVE THE BOLT FASTENING THE BRAKE ARM TO THE BRAKE COVER PANEL BY TURNING IT
COUNTERCLOCKWISE WITH YOUR FINGERS OR THE SCREWDRIVER. IF NECESSARY, USE THE 8MM WRENCH TO HOLD THE
NUT ON THE BACK SIDE OF THE BRAKE ARM STEADY SO THAT YOU CAN MORE EASILY TWIST THE BOLT.
4. SET THE BOLT, WASHER, AND NUT ASIDE.
FRONT FORK
18
BRAKE COVER PANEL
BOLT
SCREWDRIVER
BRAKE MECHANISM
NUT
WASHER
BRAKE ARM
8 MM
WRENCH
