Securing the Bell

1.10
YOU WILL NEED THE PHILLIPS-HEAD SCREWDRIVER
1. LOOSEN (BUT DO NOT REMOVE) THE SCREW ON THE BELL CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1 - 2
ROTATIONS WITH THE SCREWDRIVER.
2. ROTATE THE BELL AROUND THE HANDLEBAR UNTIL IT IS IN A POSITION WHERE THE BELL TAB CAN EASILY BE REACHED BY
THE RIDER'S RIGHT-HAND THUMB WHEN HOLDING ONTO THE HANDLEBAR.
3. TIGHTEN THE SCREW BY TURNING IT CLOCKWISE WITH THE SCREWDRIVER TO SECURE THE BELL CLAMP IN PLACE.
BELL
SCREW
SCREWDRIVER
38
BELL TAB
