4. PLACE THE WHEEL IN THE FRONT FORK SUCH THAT THE FOLLOWING CONDITIONS ARE MET:
·
THE SPACES MENTIONED IN STEP 3 REST IN THE WEDGES ON THE END OF THE FRONT FORK.
·
THE WASHERS AND AXLE NUTS ARE ON THE OUTER SIDES OF THE FORK.
·
THE BRAKE MECHANISM ON THE WHEEL IS ON THE LEFT SIDE OF THE BIKE.
FRONT FORK WEDGE SPACE
BRAKE
FRONT FORK
AXLE NUT & WASHER
FRONT FORK
15
