4. TO SECURE THE SEAT IN PLACE, CLOSE THE LATCH ON THE SEAT CLAMP.
5. CHECK THAT THE SEAT IS SECURE: USE YOUR HAND TO PUT DOWNWARD PRESSURE ON THE SEAT. IF THE SEAT POST
SLIPS FURTHER DOWN INTO THE TUBE, BRING IT BACK TO POSITION AND TIGHTEN THE CLAMP BY TURNING THE
KNOB CLOCKWISE.
IMPORTANT: IF YOU CANNOT OPEN OR CLOSE THE SEAT POST CLAMP, THE KNOB MAY BE TOO TIGHT. LOOSEN THE
KNOB BY TURNING IT 1/2 COUNTERCLOCKWISE ROTATION AT A TIME UNTIL YOU CAN UTILIZE THE LATCH.
(
opposite side
32
CLAMP KNOB
-
)
not shown
SEAT
SEAT POST
SEAT CLAMP
CLAMP LATCH
