Jetson Zephyr Manual page 23

2. USING YOUR FINGERS, PULL THE BRAKE LEVER TOWARDS THE BRAKE ARM.
3. WHILE HOLDING THE BRAKE LEVER IN THAT POSITION, USE THE FINGERS ON YOUR OTHER HAND TO PULL THE
END OF THE BRAKE CABLE TAUT.
4. CONTINUE HOLDING THE CABLE TAUT WHILE YOU RELEASE THE BRAKE LEVER.
5. RE-TIGHTEN THE NUT THAT YOU LOOSENED IN STEP 1 BY TURNING IT CLOCKWISE WITH THE 10MM WRENCH.
6. REPEAT STEPS 1 – 4 ON THE REAR BRAKE.
7. CONDUCT A BRAKE SAFETY & FUNCTIONALITY CHECK (PAGE 46) ON BOTH BRAKES.
BRAKE CABLE
BRAKE LEVER
BRAKE CABLE
3
FRONT FORK
2
BRAKE ARM
BRAKE LEVER
BRAKE MECHANISM
21
