5. WORKING ON ONE SIDE OF THE BIKE, LOOSEN AND THEN
REMOVE THE BOLT AT THE BOTTOM OF THE FRONT FORK NEAR
THE AXLE NUT BY TURNING IT COUNTERCLOCKWISE WITH THE
SCREWDRIVER. REMOVE THE WASHER NEXT TO IT, AND SET THE
HARDWARE ASIDE.
6. ALIGN THE HOLE AT THE END OF THE FENDER BRACE WITH THE
HOLE FROM WHICH YOU JUST REMOVED THE BOLT.
7. SLIDE A WASHER ONTO ONE OF THE BOLTS AND REINSERT
(BUT DO NOT TIGHTEN) THE END OF THE SCREW WITH WASHER
THROUGH BOTH ALIGNED HOLES.
8. REPEAT STEPS 6 – 8 ON THE OTHER SIDE OF THE BIKE.
FENDER BRACE
FRONT FENDER
PHILLIPS-HEAD SCREWDRIVER
BOLT
WASHER
FENDER BRACE
