E-26 Understanding Drive Arrays
DAZ9-12.EPS
Drive Indicators
OK to remove drive if not part
of fault-tolerant configuration
OK to remove failed drive
DO NOT remove drive
DO NOT remove drive
DO NOT remove drive
DO NOT remove drive
DO NOT remove drive
OFF
ON
Figure E-12. Hot-plug drive replacement conditions
Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002
File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM
