Analog Board #1 - Frick QUANTUM Maintenance Manual

S90-010 M
Page 38
LEAVING PROCESS
TEMPERATURE
BALANCE PISTON
REG IF REQUIRED
REMOTE 4-20 MA
SLIDE VALVE POSITION
FRICK QUANTUM CONTROL PANEL

ANALOG BOARD #1

SUCTION
TEMP
DISCH
TEMP
OIL
TEMP
SEP
TEMP
OIL
PRESS
FILTER
PRESS
DISCH
PRESS
SUCT
PRESS
SYSTEM
DISCHARGE
REMOTE
CONTROL
SETPOINT
SLIDE
VALVE
SLIDE
STOP
MOTOR
AMPS
MAINTENANCE
U13
1 2 3
U4
U15
1 2 3
1 2 3
1 2 3
1 2 3
PIN 8 = ANALOG OUTPUT #4
-
PIN 7 = GND
PIN 6 = ANALOG OUTPUT #3
PIN 5 = GND
PIN 4 = ANALOG OUTPUT #2
PIN 3 = GND
PIN 2 = ANALOG OUTPUT #1
PIN 1 = GND
