S90-010 M
Page 24
SUCTION PRESSURE CONTROL MODE #1
Capacity control setpoint
Upper proportional band
Upper dead band
Upper cycle time
Lower proportional band
Lower dead band
Lower cycle time
Autocycle start pressure
Autocycle start delay
Autocycle stop pressure
Autocycle stop delay
Low suction pressure stop load
Low suction pressure force unload
Low suction pressure alarm
Low suction pressure alarm delay
Low suction pressure shutdown
Low suction pressure shutdown delay
SUCTION PRESSURE CONTROL MODE #2
Capacity control setpoint
Upper proportional band
Upper dead band
Upper cycle time
Lower proportional band
Lower dead band
Lower cycle time
Autocycle start pressure
Autocycle start delay
Autocycle stop pressure
Autocycle stop delay
Low suction pressure stop load
Low suction pressure force unload
Low suction pressure alarm
Low suction pressure alarm delay
Low suction pressure shutdown
Low suction pressure shutdown delay
FRICK QUANTUM CONTROL PANEL
MAINTENANCE
CAPACITY CONTROL SETPOINTS
setting
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
setting
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
_____
default
range
20 psig
30" - 135 psig
4 psig
0 - 20 psig
. 5 psig
0 - 10 psig
3 sec.
0 - 60 sec.
4 psig
0 - 20 psig
. 5 psig
0 - 10 psig
3 sec.
0 - 60 sec.
25 psig
30" - 135 psig
1 min.
0 - 60 min.
15 psig
30" - 135 psig
1 min.
0 - 60 min.
10 psig
30" - 135 psig
5 psig
30" - 135 psig
2 psig
30" - 135 psig
2 sec.
0 - 60 sec.
0 psig
30" - 135 psig
3 sec.
0 - 60 sec.
default
range
20 psig
30" - 135 psig
4 psig
0 - 20 psig
.5 psig
0 - 10 psig
3 sec.
0 - 60 sec.
4 psig
0 - 20 psig
.5 psig
0 - 10 psig
3 sec.
0 - 60 sec.
25 psig
30" - 135 psig
1 min.
0 - 60 min.
15 psig
30" - 135 psig
1 min.
0 - 60 min.
10 psig
30" - 135 psig
5 psig
30" - 135 psig
2 psig
30" - 135 psig
2 sec.
0 - 60 sec.
0 psig
30" - 135 psig
3 sec.
0 - 60 sec.
