Frick QUANTUM Maintenance Manual page 16

S90-010 M
Page 16
BOARD #1, INPUT CHANNEL #3 - OIL TEMPERATURE
J3 out 0-5 volt input
1-2 4-20 ma. input
2-3* ICTD input (standard setting)
BOARD #1, INPUT CHANNEL #4 -
OIL SEPARATOR TEMPERATURE
J4 out 0-5 volt input
1-2 4-20 ma. input
2-3* ICTD input (standard setting)
BOARD #1, INPUT CHANNEL #5 -
LEAVING PROCESS TEMPERATURE**
J5 out 0-5 volt input
1-2 4-20 ma. input
2-3* ICTD input (standard setting)
BOARD #1, INPUT CHANNEL #6 - OIL PRESSURE
J6 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
BOARD #1, INPUT CHANNEL #7 - OIL FILTER PRESSURE**
J7 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
BOARD #1, INPUT CHANNEL #8 - DISCHARGE PRESSURE
J8 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
BOARD #1, INPUT CHANNEL #9 - SUCTION PRESSURE
J9 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
BOARD #1, INPUT CHANNEL #10 - BALANCE PISTON
PRESSURE**
J10 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
BOARD #1, INPUT CHANNEL #11 - SYSTEM DISCHARGE
PRESSURE**
J11 out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
BOARD #1, INPUT CHANNEL #12 - REMOTE CAPACITY
CONTROL SETPOINT**
J12 out 0-5 volt input
1-2* 4-20 ma. input (standard setting)
2-3 ICTD input
* = standard setting
** If applicable
† RWF compressor standard setting
FRICK QUANTUM CONTROL PANEL
MAINTENANCE
BOARD #1, INPUT CHANNEL #13 - REMOTE SLIDE
VALVE POSITION**
J13
BOARD #1, INPUT CHANNEL #14 - SLIDE VALVE**
J14
J15
J16
BOARD #1, INPUT CHANNEL #15 - SLIDE STOP**
J17
J18
J19
BOARD #1, INPUT CHANNEL #16 - MOTOR AMPS
0-5 amp CT input*
0-5 volt input
4-20 ma. input
ICTD input
BOARD #1, OUTPUT CHANNEL #1 - FUTURE
J26
J39
IC's
BOARD #1, OUTPUT CHANNEL #2 - FUTURE
J25
J40
IC's
BOARD #1, OUTPUT CHANNEL #3 - SLIDE VALVE POSI-
TION \ CAPACITY**
J24
J41
IC's
BOARD #1, OUTPUT CHANNEL #4 - REMOTE CONTROL
SETPOINT**
J23
J42
IC's
out 0-5 volt input
1-2* 4-20 ma. input (standard setting)
2-3 ICTD input
in All other input types. (0-5 volt, 4-20 ma., ICTD)
out* Slide valve potentiometer input. (std setting)
out* 0-5 volt input (standard setting)
1-2 4-20 ma. input
2-3 ICTD input
in All other input types. (0-5 volt, 4-20 ma., ICTD)
out* Slide valve potentiometer input. (std setting)
in† All other input types. (0-5 volt, 4-20 ma., ICTD)
out* Slide stop potentiometer input. (std setting)
out* 0-5 volt input (standard setting)
1-2† 4-20 ma. input
2-3† ICTD input
in† All other input types. (0-5 volt, 4-20 ma., ICTD)
out* Slide valve potentiometer input. (std setting)
J20
out
(std)
out
in
out
1-2 0-20 ma. output.
2-3 4-20 ma. output
1-2 4-20 ma. output
2-3 0-20 ma. output
install U15 & U7 Connect to P10 terminals 1 & 2
1-2 0-20 ma. output.
2-3 4-20 ma. output
1-2 4-20 ma. output
2-3 0-20 ma. output
install U15 & U6 Connect to P10 terminals 3 & 4
1-2 0-20 ma. output.
2-3* 4-20 ma. output (standard setting)
1-2* 4-20 ma. output (standard setting)
2-3 0-20 ma. output
install U15 & U5 Connect to P10 terminals 5 & 6
1-2 0-20 ma. output.
2-3* 4-20 ma. output (standard setting)
1-2* 4-20 ma. output (standard setting)
2-3 0-20 ma. output
install U15 & U4 Connect to P10 terminals 7 & 8
J21 J22
out in
(std) (std)
out out
out out
in out
