2-10.11 LAN Connector (85MR3-RL Only)

One RJ45 connector is on board for network connection.
Yellow LED "On" to indicate
Network hub is in connection
with the system.
Green LED blinks to indicate
that data transmission is
undergoing in 10/100 Base T
mode.
