- Page 1 Step 1 LED Display Controller Thunderview_S1 User Manual Product Version: V1.0.1 Document Number: NS110100640...
- Page 2 Xi’an NovaStar Tech Co., Ltd. Statement You are welcome to use the product of Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as NovaStar). This document is intended to help you understand and use the product. For accuracy and reliability, NovaStar may make improvements and/or changes to this document at any time and without notice.
-
Page 3: Change History
LED Display Controller Thunderview_S1 User Manual Change History Change History Version Release Date Description V1.0.1 2018-08-23 Changed pictures in the document. V1.0.0 2017-11-20 First release www.novastar.tech... -
Page 4: Table Of Contents
6.6.6 Factory Reset ............................12 6.6.7 Returning to Home Screen ........................12 6.6.8 OLED Brightness ............................ 12 6.6.9 Hardware Version ........................... 12 6.7 Communication Settings ..........................12 6.8 Language ..............................12 7 Quick Screen Configuration ..................14 8 Specifications ....................... 15 www.novastar.tech... -
Page 5: Safety Instructions
1 Safety Instructions Safety Instructions To prevent potential danger, please use this device according to the following rules. In case of any damage, please contact NovaStar after-sales department for maintenance, rather than have the device disassembled and maintained by non-professionals. -
Page 6: Overview
User Manual 2 Overview Overview The S1 is NovaStar's new generation of Thunderview series display controller especially designed for high-end display applications. With multiple I/O connectors and control connectors, it is ideal for different applications, such as broadcasting and television, indoor high-end screens with fine pitch, rental for stage, security monitoring, etc. -
Page 7: Appearance
Standard HDMI 1.4a input Supports 8-bit/12-bit. HDMI For 8-bit, supports RGB 4:4:4 1080P. For 12-bit, supports YCbCr 4:2:2 1080P. Inputs Single-link DVI Users can customize the resolution. Maximum horizontal resolution: 3840 pixels Maximum vertical resolution: 3840 www.novastar.tech... - Page 8 RJ45 (TCP/IP) control connector Control Control connector that connects to the upper USB (Type-A) computer USB (Type-B) Cascade connector Power 100–240VAC@50/60Hz AC power input Switch ON/OFF Note: The type-A USB port is prohibited from being connected to the upper computer directly. www.novastar.tech...
-
Page 9: Dimensions
LED Display Controller Thunderview_S1 User Manual 4 Dimensions Dimensions Unit: mm www.novastar.tech... -
Page 10: Home Screen
As shown in the figure above, the HDMI is selected, which means the HDMI-type input source is operating. ⑤ Loading capacity status of outputs ⑥ Loading capacity status of the device ⑦ Screen brightness PRIMARY (primary device)/BACKUP (backup device) Statuses of control connector: GenLock. www.novastar.tech... -
Page 11: Operations
1920x1080@60HZ and the loading capacity of the device is up to 3840x1080@60Hz. Backup Mode When the Backup mode is selected, the Output 1 (OUT1 and IN1) is used as the primary output connector and the Output 2 (OUT2 and IN2) is used as the backup output connector. www.novastar.tech... -
Page 12: Screen Settings
BACK button to exit the current operation. Ensure that the cabinets are connected one by one according to one direction Ensure that the Ethernet Port 1 is at the beginning position of the whole data flow. www.novastar.tech... -
Page 13: Advanced Configuration
Select a proper resolution from the resolution presets and press the knob to save the setting. Method 2: Set a Custom resolution. After choosing Custom, set Width (H), Height (V) and Refresh Rate. Then, select Apply and press the knob to save the settings. www.novastar.tech... -
Page 14: Display Control
When the Mapping function is enabled, each cabinet's receiving card No. and Ethernet port information will be displayed in the corresponding area on the LED display. Therefore, the user can obtain the position of the receiving cards and the data flow. www.novastar.tech... -
Page 15: Loading Cabinet Files
Step 2 Import the cabinet configuration files to the S1. Step 3 Load the cabinet configuration files. 6.6.4 Saving to Hardware Save all configuration parameters concerning the receiving cards to the receiving cards and those parameters will not be lost even after the device is powered off. www.novastar.tech... -
Page 16: Redundancy
When setting the network manually, the user can set the device's IP address (cannot conflict with IP addresses of other devices) and subnet mask, or reset the network parameters. 6.8 Language Change the user interface language of the device. www.novastar.tech... - Page 17 LED Display Controller Thunderview_S1 User Manual 6 Operations www.novastar.tech...
-
Page 18: Quick Screen Configuration
Step 5 (Optional) Communication settings Set the control mode and network mode of the device. For details, see Communication Settings. Step 6 (Optional) Language Set the user interface language of the current device. Chinese and English are available. For details, see Language. www.novastar.tech... -
Page 19: Specifications
Input voltage 100–240 VAC Rated current 1.5 A Rated power consumption 20.0 W Operating temperature -20° C–60° C Ambient humidity 10%RH–90%RH, no condensation Dimensions 482.6 mm x 288.5 mm x 45.0 mm Net weight 3.85 Kg Space required 1 RU www.novastar.tech...
