Connector
JTPM1
JUIDB1
JUSBRJ45
M.2_MH1-M.2_MH4
USB0/1
VGA
USB0/1
VGA
Note: For detailed instructions on how to configure Network Interface Card (NIC) settings,
refer to the Network Interface Card Configuration User's Guide posted on the webpage
www.supermicro.com/support/manuals/.
Description
Trusted Platform Module/Port 80 Header
Unit Identifier Switch
Rear I/O USB2/3 Ports (USB 3.2 Gen 1) and Dedicated BMC LAN Port
M.2 Mounting Holes
Front Accessible USB 2.0 Headers
VGA Port
USB 2.0 Headers
VGA Port
