1.2 System Features
The following views of the system display the main features. Refer to
specifications.
Front View
Power LED
HDD LED
Power
Button
Feature
Description
The main power switch applies or removes primary power from the power supply to the
Power button
server but maintains standby power. To perform most maintenance tasks, unplug the
system to remove all power.
Indicates power is being supplied to the system power supply units. This LED is
Power LED and
illuminated when the system is operating normally. Indicates hard disk drive activity
HDD LED
when flashing.
Figure 1-1. Front View
System Features: Front
Figure 1-2. Control Panel
8
Chapter 1: Introduction
Appendix B
for additional
