1.1 Overview
This chapter provides a brief outline of the functions and features of the SuperServer
SYS-E302-12A-4C/8C. It is based on the A3SPI-4C-LN6PF/8C-LN6PF motherboard and the
CSE-302iL chassis.
The following provides an overview of the specifications and capabilities.
Motherboard
Chassis
Processor
Support
Memory
Drive Support
Expansion Slots
I/O Ports*
System Cooling
Power
Form Factor
Notes: A Quick Reference Guide can be found on the product page of the Supermicro website.
The following safety models associated with the SYS-E302-12A-4C/8C have been certified
as compliant with UL or CSA: E302iL-15, E302iL-A15A3.
Chapter 1
Introduction
System Overview
SYS-E302-12A-4C: A3SPI-4C-LN6PF
SYS-E302-12A-8C: A3SPI-8C-LN6PF
CSE-302iL
SYS-E302-12A-4C: Single Intel Atom® Processor C5315
SYS-E302-12A-8C: Single Intel Atom® Processor C5325
Up to 128GB of DDR4 ECC RDIMM memory to 2400 MT/s (4C) and 2933 MT/S (8C)
Two M.2 slots (PCIe)
One M.2 (PCIe 3.0 x2 / USB 3.0 / SATA3, B-Key 3052)
One M.2 (PCIe 3.0 x4, M-Key 2280)
One 2.5" SSD
One PCIe 3.0 x2 (in x8)
One OCuLink supports PCIe x4/SATA/NVMe
One RJ45 Dedicated IPMI LAN port
Four RJ45 Gigabit Ethernet LAN ports
Two SFP+ 10GbE LAN ports
Two USB 3.0 port(s) (2 USB)
One VGA port
Fanless
One external 150 watt DC power adapter
Compact: 11.6" x 2.9" x 8.1" (295 x 73 x 205mm) (WxHxD)
7
Chapter 1: Introduction
