Rear View
IPMI LAN Port
Power
Input
Feature Description
The main power switch applies or removes primary power from the power supply to the
Power input server but maintains standby power. To perform most maintenance tasks, unplug the
system to remove all power.
LAN Ports One dedicated IPMI LAN port, four GbE LAN ports, two 10 GbE SFP+ ports
USB Ports Two USB 3.0 ports
VGA Port Video port
SATA Drive Bay 2.5" drive bay for SATA SSD
K-slot for lock Accepts a standard Kensington cable locking device (not included).
Figure 1-2. System: Rear View
System Features: Rear
9
Chapter 1: Introduction
VGA Port
Two SFP+ Ports
Four GbE LAN Ports
USB 3.0 Ports
SATA Drive Bay
K-slot
