11.2 OBSERVER-i – OPERATING MODES
The following is a summary of the Observer-i Operating Modes:
11.3 OBSERVER-i – CALIBRATION SUBMODE
This mode indicates the calibration status during the calibration.
11.4 CALIBRATION EVENT LOG – CAUSE DESCRIPTION
This event cause indicates the result of calibration.
Table 8: Observer-i Calibration Event Log – Cause Description
Operating Mode
Start Up
Operational
Acoustic Test
Calibration
Fault
Set Up
SB100 Test
Alarm Test
Cal. Pending
Piezo Calibrate
Alarm
Show Rev.
Not Used
Not Used
Not Used
Not Used

Table 6: Observer-i Operating Modes

Operating Submode
Apply 1701
Cal. in Progress
Cal. Adjustment
Cal. OK
Cal. Error

Table 7: Observer-i Calibration Submode

Calibration Event Cause
Calibration OK
Calibration Adjusted
Calibration Error
Value in Hex
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
0x0100
0x0200
0x0400
0x0800
0x1000
0x2000
0x4000
0x8000
Value in Hex
0x0001
0x0002
0x0004
0x0008
0x0010
Value in Hex
0x0004
0x0005
0x0006
30
