10.0

DEVICE SPECIFIC COMMANDS

The Device Specific commands are used strictly for the unique features of the Observer-i and at the
discretion of General Monitors, an MSA company. They are described here in Section 10.0 and are
summarized in

10.1 COMMAND #132: DO ALARM TEST

This command turns Alarm test mode on/off.
Request Data Bytes
Byte
0 Unsigned 8
Response Data Bytes
Byte
0 Unsigned 8
Command-Specific Response Codes
Code
0 Success
1 - 15
16 Error
17 - 127

10.2 COMMAND #136: SET ALARM LEVEL

This command sets the Alarm Level.
Request Data Bytes
Byte
0 Unsigned-8
Response Data Bytes
Byte
0 Unsigned-8
Table 5.
Format
N/A
Format
N/A
Class
No Command-Specific Errors
Undefined
Access Restricted
Undefined
Format
Alarm Level in dB
Format
Alarm Level in dB
Description
Description
Description
Description
Description
11
